Our Core Expertise What We Do
We deliver comprehensive, end-to-end ASIC design solutions across the full semiconductor lifecycle. Our expertise spans architecture, analog and digital design, verification, physical implementation, and signoff—enabling high-performance, scalable, and reliable silicon.
Architecture & IP Design
-
At spintronicsAI with extensive research we will build data models wrt to your product requirements and schedule constraints.
-
These Data models help in exploring trade offs between business, financial and technical constraints for achieving right TTM
-
Detailed algorithms will be built for tracking every stage of implementation and signoff
-
With multiple handoffs our custom flows will ensure the quality of the design is maintained throughout the design cycle
-
Custom built signoff flows will ensure quality checklist from customer is met and ensure design is ready for next stage of implementation.

-
Standard Cell
-
High Density, High Speed, Low power
-
Design, Layout and Characterization
-
Analog and Mixed Signal
-
ADC, DAC, Regulator, PLL, DLL, Transmitter (TX), Receiver (RX)
-
High-Speed Serdes, DDR, other PHY Interfaces, USB, Die-to-Die etc
-
Post Layout Extraction (PEX) Simulation and Verification
-
Physical Verifications (ANT, DRC, DFM, LVS, ERC, PAD, PERC, ESD/Latch-up, EMIR/SHE etc)
-
Memory, IO PAD Library Design & Simulation, AMS Verification
-
Block level, IP level and Chip level Layout
Circuit and Layout Design

RTL Design and Integration
-
Design Implementation
-
Translating power spec to UPF
-
Design and UPF validation
-
LINT and CDC checks
-
RTL Handoff
Verification
-
Verification Service for ASIC, SOC and FPGA Design
-
VMM, OVM, UVM, RVM, eRM methodology based verification
-
Intellectual Property Verification
-
Verification Assessment
-
Verification Planning
-
Verification Environment Development using bus functional models, monitors, checkers, test pattern/packet generator and score boards
-
Functional verification
Digital Frontend Design


-
Floorplanning & Partitioning – Efficient block partitioning, area budgeting, and hierarchical planning
-
Power Planning & Power Grid (PG) – Robust power grid design, IR/EM-aware implementation
-
Low Power Implementation – UPF/CPF-based design, power gating, multi-voltage domains
-
Placement & Optimization – Timing-driven placement and congestion optimization
-
Clocking (CTS) – Clock tree synthesis, skew/jitter optimization, clock distribution
-
Routing (Global & Detailed) – Signal integrity-aware routing with DRC clean closure
-
STA (Static Timing Analysis) – Setup/hold closure, multi-corner multi-mode (MCMM) analysis
-
Block & Chip-Level Implementation – End-to-end execution from block to full-chip level
-
Physical Verification (PV) – DRC, LVS, ERC, antenna checks, and signoff compliance
-
Signoff & Tapeout Readiness – Ensuring design meets foundry and product-level requirements
Digital Backend Design
-
Scan Insertion & Compression – Efficient scan chains with reduced test data
-
Boundary Scan (1149.x) – Enables board-level and interconnect testing
-
MBIST / LBIST – Built-in self-test for memories and logic blocks
-
Test Point Insertion – Improves fault coverage and observability
-
OCC & Clocking – Supports at-speed testing with controlled clocks
-
ATPG & Pattern Validation – Test pattern generation, simulation, and debug
-
Fault Coverage & GLS – Ensures high defect detection and design correctness
-
DFT Signoff & Bring-up – Tapeout readiness and silicon validation support
DFT


Signoff
-
Timing closure using MCMM methodologies, AI based support for faster TTM
-
LP static signoff for RTL/logical-netlist/Physical-Netlist using CLP/VCLP
-
RTL-Netlist and Netlist-Netlist Equivalency Signoff using Iec/Formal
-
Dynamic-power signoff for power-corner
